二组分聚氨酯弹性体浇注机(电热式)
It is used for the production of MOCA or BDO as chain expansion agent casting type polyurethane elastomer products, such as industrial rubber roller, mining screen plate, hydraulic sealing ring, photovoltaic guide wheel, automotive steering shaft ball bowl, oil cleaner, current cyclone, transportation pipeline inner village.
-High cost performance;
-Multi-point segment temperature control, uniform temperature;
-The tank bottom high speed heating device greatly improves the heating efficiency;
-Easy access for maintenance;
-Silent type vacuum pump, small and beautiful;
-Humanized design of feeding and maintenance platform;
Model / Type | CPU20F(S)-H1 | CPU20F(S)-H2 | CPU20F(S)-H3 | CPU20F(S)-H4 | CPU20F(S)-H5 |
Output capability (g / min) | 200~800 | 1000~3000 | 2000~5000 | 3000~8000 | 5000~15000 |
Component name | Mixing ratio (adjustable) | Operating temperature (℃) | dynamic viscosity (CPS) |
A (TDI, MDI Pre-polymer) | 100 | 60~100 | <5000 |
B(MOCA or BDO) | 5~20 | 80~125 | <500 |
S(Color or additive ) | 0.3~1 | normal temperature | 50~2000 |
